DMP Electronics EBOX-335xDX3 Series User Manual

EBOX-335xDX3 Series User Manual
DMP Electronics Inc. 12
System Specifications
CPU
Vortex86DX3 Dual core (1GHz)
*Windows platform 64-bit not support
Main Memory
1GB DDR3 (32-bit DRAM bus, EBOX-3350DX3 Series)
2GB DDR3 (32-bit DRAM bus, EBOX-3352DX3 Series)
BIOS
AMI BIOS
Display
VGA: Resolution up to 1920 x 1080 pixels
HDMI: Resolution up to 1920 x 1080 pixels
I/O Connectors
1. USB 2.0 x 3 (2 at front, 1 at rear)
2. SATA (for SATA DOM) x 1(*)
3. SD Card slot x1
4. Micro SD card slot x1(*)
5. 10/100 Mbps LAN x1 or 1G LAN x1
6. Mic in x 1 + Line out x 1
7. Standard Mini PCIe (not support USB Signal) x1(*)
8. RS-232 port x2
9. RCA connector x2(*)
*2, 4, 7, 9 available in RCA Series.
Dimension & Weight
95 x 95 x 20mm/ 280g
95 x 95 x 35mm/ 360g
Power consumption
EBOX-335xDX3 Series: DC +5V@2A
EBOX-335xDX3-RCA Series: DC +5V@1.5A
Supported Operating system
Windows 7 Home/ Pro
Windows 7 Embedded
Windows XP Home/ Pro
Windows XP Embedded
Linux OS (Support list on EBOX website)
