LCD Keypad Installation Guide 13
ACTIVATE ZONE 3
EXIT: NO YES
Zone 3 Exit (7073/7073A, 793 only)
Select YES to enable the Request to Exit feature
on zone 3. When zone 3 shorts, the keypad relay
activates. During this time, the user can open the
protected door to start the programmed Soft-Shunt
entry/exit timer. If the door is not opened within
the time programmed in the Zone 3 REX Strike
Time, the relay restores the door to its locked
state. When shorted, this zone activates the
keypad relay. No panel programming is required.
ZN 3 REX STRIKE
TIME: 5
Zone 3 REX Strike Time
(7073/7073A, 793 only)
Enter the number of REX seconds to elapse. Range
is from 5 to 250 seconds. Press any select key to
enter the number of seconds. The default is 5
seconds.
ALL?: NO YES
DELAY: 2
Arming/Disarming Wait Time
(7063/7063A, 7073/7073A, 693/793 only)
Select the number of seconds the keypad should
wait when an area system displays ALL? NO YES
during arming/disarming or a HOME/SLEEP/AWAY
system waits during arming only. If NO or YES, or
HOME, SLEEP, or AWAY is not manually selected
before the delay expires, the keypad automatically
selects the YES or the AWAY key. Select zero (0)
to disable this feature. The delay can be one to
nine (1-9) seconds. The delay also occurs when
any credential is presented for arming the Home/
Sleep/Away system. After a card is presented,
HOME SLEEP AWAY displays. The keypad waits
the programmed number of seconds before
automatically selecting AWAY.
CARD OPTIONS
DMP CUSTOM
Card Options
(7063/7063A, 7073/7073A, 693/793 only)
Select DMP to indicate the reader sends a 26-bit
DMP data string. To save the DMP option, press the
left top row Select key under DMP. Default is DMP.
Select CUSTOM if using a non-DMP credential. To
select CUSTOM press the right top row Select key.
