DMXking.com • JPK Systems Limited • New Zealand
0129-700-4.4
2
MAIN FEATURES
− Wide input power range 5-24Vdc.
− Power from USB-C (pixel power outputs excluded)
− OEM board available for integration into your custom LED designs
− DIN rail and wall mount using built in clips
− Static or DHCP IPv4 network addressing
− Supported operating systems: Windows, MacOS, Linux, iOS, Android
− 4 Independent pixel output ports each with 8A supply capability
− 2 Independent DC power inputs
− 1x DMX512 IN/OUT port
− Directly drives WS2811, WS2812, WS2812B, WS2813, WS2815, WS2822S UCS1903, UCS2903, UCS2912, UCS8903,
UCS8904, PL9823, TM1934, APA101, SK9822, APA102, APA104, APA106, APA107, NS107, INK1002, INK1003, SM16703,
SK6812, WS2801, LPD6803, LPD8806, DMX512-P and many more compatible LED strips
− Selectable clock/data rate to suit long cables or fast output
− Up to 1020 RGB pixels or 768 RGBW pixels per output spanning 6 DMX universes (4080 RGB pixels / 24 universes per
LeDMX4 MAX)
− Up to 510 16bit RGB pixels or 384 16bit RGBW pixels per output
− Automatic RGB, RGBW color order correction or raw mapping options
− Per pixel intensity control for APA102/SK9822 utilizing the 5bit current pre-regulator
− Master Level control independent of incoming universe streams
− Flexible Full Mapping option for outputs permitting any start address and zig-zag corrections of RGB, RGB16, RGBW and
RGBW16 pixel types
− Alternate Full Mapping and Master Level changeover with sACN Priority threshold
− Null pixel support for longer runs to first active pixel
− Art-Net broadcast, Art-Net II,3 & 4 unicast, sACN/E1.31 Multicast and sACN Unicast support
− HTP Merging of 2 Art-Net or sACN sources in any combination
− Merge 2 streams of Art-Net/sACN or DMX input -> Pixel universe output
− DMX512 Input Port -> Pixel universe output
− sACN Priority takeover for multi-tier controller arrangements
− Mix and match ArtNet with sACN merge/priority sources
− User configuration of Art-Net Node short and long names
− Fully compatible with *ALL* software and hardware that supports Art-Net I, II, 3 & 4 and sACN protocols
− Works with your existing console if Art-Net or sACN external nodes are supported
− Universe Sync Art-Net, sACN and Madrix Post Sync
− Recording and playback to microSD card (not included). See eDMX MAX Record / Playback manual
− Standalone show playback without computer or network connection
− Internal clock with optional battery backup for timed playback. NTP time sync.
− Configuration utility with basic Art-Net output/input test functionality
IMPORTANT: In many LED pixel installations, especially where the majority of pixels may be running simultaneously at full
brightness, it is necessary to inject DC power at various points along the pixel strip or string. Although the LeDMX4 MAX can only
provide up to 8A per output port terminal block this is not a limitation since currents higher than that would require power
injection along the strip anyhow. Contact DMXking technical support for additional advice.
eDMX MAX translates Art-Net 00:0:0 to Universe 1 (i.e. offset by 1) so there is an
easy mapping between sACN/E1.31 and Art-Net.
