STATUS LED TABLE
LED
Indication
Protocol
Protocol activity. Flash Red = Art-Net/sACN. Solid Red = Bootloader mode
Link/Act
Network activity. Green = Link, Flash = Traffic
Port 1
Pixel port 1 activity
Port 2
Pixel port 2 activity
Port 3
Pixel port 3 activity
Port 4
Pixel port 4 activity
3. DEFAULT CONFIGURATION
LeDMX4 MAX units ship with default static IP address settings. Please reconfigure for your local area network requirements before
use.
Default configuration is for WS2811/2812 pixel output with automatic RGB color order correction and 1 DMX universe mapping
to 170 RGB pixels per output.
Network Tab
Parameter
Default Setting
Network Mode
Static IP
IP Address
192.168.0.113
Subnet Mask
255.255.255.0
Default Gateway
192.168.0.254
IGMPv2 Unsolicited
Report
Unchecked
Settings Tab
Parameter
Default Setting
Update Rate
30Hz - Universe Sync will override.
Master Level
255 – Full output intensity.
Alternate Master Level
255 – Full output intensity.
Alt. mapping priority threshold
0 – Alternate Mapping Disabled.
