Port Tabs (1-4)
Parameter
Default Setting
Pixel Type
WS2811
Pixel Count
170
Null Pixels
0
Color Order
GRB
Primary Start Universe
1,2,3,4 (Ports 1,2,3,4 respectively)
Primary Start Channel
1
Primary Pixel Group Size
1
Primary ZigZag
0
Primary Direction
Normal (unticked)
Alternate Start Universe
1,2,3,4 (Ports 1,2,3,4 respectively)
Alternate Start Channel
1
Alternate Pixel Group Size
1
Alternate ZigZag
0
Alternate Direction
Normal (unticked)
Port Tab A (DMX512 port)
Parameter
Default Setting
Async Update Rate
40 [DMX512 frames per second]. Universe Sync will override.
Port Operation Mode
DMX-OUT
Timeout all sources
Unchecked
Channel Offset
0
Fixed IP
0.0.0.0 [Only for DMX IN – Unicast to 1 IP address only]
Merge Mode
HTP
Full DMX Frame
Unchecked
Broadcast Threshold
10 [Art-Net II/3/4 unicasting up to 10 nodes]. Set to 0 for Art-Net I
broadcast on DMX IN ports.
Unicast IP [DMX-IN]
0.0.0.0
sACN Priority [DMX-IN]
100
