Cavity Cartridge Fuse Mini-Fuse Description
19 – – Fuse – Spare
20 – – Fuse – Spare
21 30 Amp Pink – Fuel Pump
22 – 20 Amp Yellow – Police Right Spot Lamp – Police
23 – 10 Amp Red Fuel Door/Diagnostic Port
24 – 10 Amp Red Integrated Center Stack
25 – 10 Amp Red Tire Pressure Monitor
26
– 15 Amp Blue Cygnus Transmission Module
(Charger/300)/Electronic Shift
Module (Charger/300)
27 – 25 Amp Clear Amplifier – If Equipped
31 – 25 Amp Breaker Power Seats – If Equipped
32 – 15 Amp Blue HVAC Module/Cluster
33
– 15 Amp Blue Ignition Switch/RF Hub Module/
Steering Column Lock (300) – If
Equipped
34
– 10 Amp Red Steering Column Module/Clock
(300)
325
