38 MULTIMEDIA
NOTE:
The Launch Control RPM setting can only be
adjusted while Launch Control is not active.
After Launch Control has been aborted, ESC will
return to its current ESC mode.
Launch RPM Set-Up
To adjust the Launch RPM, drag the slider bar or
press the arrows on the touchscreen to adjust
the holding RPM. The launch RPM limit is
between the minimum and maximum RPM
values shown on the gauge, in 100 RPM
increments.
Shift Light
Your vehicle is equipped with a Shift Light
feature that illuminates the back light of the
tachometer in red within the instrument cluster
display. This feature is a visual cue to manually
up-shift using the Paddle Shifters or shifting the
transmission gear selector.
Shift Light Button
To actuate the Shift Light feature, press the
Shift Light button on the touchscreen while in
the Race Options tab, then press the Activate
Shift Light button on the touchscreen.
Activation is shown on the instrument cluster
display.
Once the Shift Light is configured on, it is only
active while the gear shifter is in the Manual or
Sport shifter position (M or S position).
NOTE:
Paddle Shifters can be used to shift, however
using the Paddle Shifters while the shifter is in
Drive (D) position will not enable the Shift Light
feature.
Shift Light RPM Set-Up
The Shift Light RPM Set-Up allows you to set the
Shift Light to illuminate for gears 1, 2, 3, 4, and
5-8. Pressing and releasing the Up/Down arrow
buttons above and below each listed gear,
the RPM values will change in increments of
250 RPM. Pressing and holding the arrows will
change the RPM values in increments of
500 RPM, ranging to 6250 RPM.
CAUTION!
Do not attempt to shift when the drive wheels
are spinning and do not have traction.
Damage to the transmission may occur.
