36 Dolby
®
Digital Cinema System Manual Issue 0.92 (Preliminary)
Installing a Dolby Digital Cinema System
Network Settings Summary
The system uses the IP addresses in Table 3-1 (x=auditorium number).
Table 3-1 Network Settings
Component IP Address Net Mask
Default
Gateway/Router
DSS220 auditorium
network
192.168.x.129 255.255.255.128 N/A
NA10 192.168.x.130 255.255.255.128 192.168.x.129
DMA8Plus 192.168.x.131 255.255.255.128 192.168.x.129
CP650 192.168.x.132 255.255.255.128 192.168.x.129
CP750 192.168.x.136 255.255.255.128 192.168.x.129
TI DLP projector
head
192.168.x.133 255.255.255.128 192.168.x.129
DFC100 (if present
in single-projector
Dolby 3D setup)
192.168.x.135 255.255.255.128 192.168.x.129
TI DLP projector 2
head (dual-
projector 3D setup
192.168.x.137 255.255.255.128 192.168.x.129
DFC100 (for dual-
projector 3D setup)
192.168.x.139 255.255.255.128 192.168.x.129
DSS220 theatre
network
192.168.241.(x+2) 255.255.255.0 N/A
DSL100 on theatre
network
192.168.241.2 255.255.255.0 N/A
Show Manager
Client or utility PC
on theatre network
192.168.241.y
(where y is any
unused number on
the theatre
network)
255.255.255.0 N/A
