What to do if the oil warning light comes on while working with my Dolmar TM-102.16 Trimmer?
If the oil warning light illuminates while you are using the Dolmar Trimmer, immediately turn the key to the «STOP» position and top up the oil level.
Why does the engine of my Dolmar TM-102.16 Trimmer stop and make an audible signal?
If the engine of your Dolmar Trimmer stops and you hear an audible signal, the electronic card's protection may have activated. This could be due to several reasons: * The battery contains electrolyte but is not charged: Recharge the battery. * Overvoltage caused by the charge regulator. * Badly connected battery (poor contact): Check the connections.
What to do if the dashboard lights up, but the starter motor doesn't run on my Dolmar TM-102.16 Trimmer?
If, when you turn the key to «START» on your Dolmar Trimmer, the dashboard lights up but the starter motor doesn't engage, consider the following: * The battery might be insufficiently charged: Recharge the battery. * The battery charger fuse might be blown: Replace the fuse. * Check the level in the tank. * Open the fuel stopcock. * Check fuel filter. * Ensure spark plug caps are firmly fitted. * Verify that the electrodes are clean and have the correct gap.
Why does my Dolmar Trimmer engine stop with no audible warning?
If the engine of your Dolmar Trimmer stops without any audible warning, it could be due to: * A disconnected battery: Check the connections. * Problems in the engine.
What to do if the dashboard of my Dolmar TM-102.16 remains off, but there is an audible signal?
If, when the key is in the «ON» position, the dashboard of your Dolmar Trimmer remains off but there is an audible signal, the electronic card's protection may have been triggered. This could be due to: * The electronic card being wet: Put the key in the «OFF» position and dry it using tepid air to address the problem. * The battery being insufficiently charged: Put the key in the «OFF» position and recharge the battery. * The battery charger fuse being blown: Put the key in the «OFF» position and replace the fuse.
Why does the blades warning light stay on when the blades are disengaged on my Dolmar Trimmer?
If the blades warning light stays lit on your Dolmar Trimmer even when the blades are disengaged, it's possible that the lever isn't returning to its disengaged position. This might be due to accumulated grass cuttings. To resolve this, free the joint of all the grass, accessing it from the inspection hatch.
What to do if the starter motor runs but the engine doesn't start on my Dolmar Trimmer?
If, when you turn the key to «START» on your Dolmar Trimmer, the starter motor runs but the engine does not start, try the following: * Clean or replace the air filter. * Flush out the float chamber. * Empty the fuel tank and refill it with fresh fuel. * Check and, if necessary, replace the fuel filter. * Reduce the forward speed and/or raise the cutting deck.
Why is my Dolmar TM-102.16 providing an uneven cut and poor grass collection?
If you experience uneven cutting and poor grass collection with your Dolmar Trimmer, consider these potential causes: * The cutting deck might not be parallel to the ground: Check the tire pressures and re-align the cutting deck to the ground. * The blade might be cutting badly: Ensure the blades are fitted properly and sharpen or replace them. * Check the tension of the belt and control cable of the blade engagement lever.
Why don't the blades engage on my Dolmar Trimmer?
If your Dolmar Trimmer blades do not engage, it could be due to several reasons: * You are not ready to engage the blades: Check that the conditions allowing starting are met. * Recharging of the battery insufficient. * The protection of the electronic card has cut in due to: battery contains electrolyte but is not charged: recharge battery. * The protection of the electronic card has cut in due to: overvoltage caused by the charge regulator. * The protection of the electronic card has cut in due to: badly connected battery (poor contact): check connections. * Battery disconnected. * The lever does not return to the disengaged position due to accumulated grass cuttings at the end of its stroke: free the joint of all the grass (accessed from the inspection hatch).
Why is my Dolmar TM-102.16 vibrating unusually while I'm working?
If you experience unusual vibrations while using your Dolmar Trimmer, it may be because: * The blades are imbalanced. * The blades are loose. Also, check and tighten all the fixing bolts of the engine and frame.
