Technical description BC100, BC200
10
5.1 Display elements
Item
in fig. 1,
page 3
LED Meaning
3 Yellow “Charging”: battery is being charged.
4 Green “Discharging”: battery is discharging.
5 Red “Incorrect polarity”: the battery has been
connected with the incorrect polarity.
➤ Please disconnect the battery from the battery
conditioner.
3 + 4 Green and yellow The connection has been broken.
➤ Check the connection to the battery.
➤ If possible, try to make a direct connection to the
battery using the adapter cable.
The fuse in the plug is defective.
Reversing the polarity of the connection terminals
will cause the fuse to blow in the 12/6 V plug.
➤ Replace the fuse.
