General information Rooop Air Conditioner (Air Distribution Box, Wall Thermostat Controls)
• Locate the thermostat 54.0 in. (1.4 m) above the floor.
• Install the thermostat on a partition, not on an outside
wall.
• Never expose the thermostat to direct heat from
lamps, the sun, or other heat-producing items.
• Avoid locations close to doors that lead outside,
windows, or adjoining outside walls.
• Avoid locations close to supply registers and the air
from them.
For thermostats installed with an optional indoor
temperature sensor in all zones, consider these
additional items:
• The thermostat may be mounted anywhere in the RV
that is convenient.
• Avoid hard to reach and hard to see areas.
• See the instructions provided with the indoor
temperature sensor for installation details.
For multiple, single zone thermostats, install each
individual thermostat in the room that the AC is
responsible for cooling.
4.7.3 Tilt requirements
When measuring for placement, perform the following
actions.
1. Make all measurements while the RV is parked on a
level surface.
2. Install the rooop component on a flat and level roof
section.
3. Use the tilt allowance table to determine the
maximum acceptable roof tilt.
Tilt allowance
Model number Maximum tilt (all directions)
FreshJet3 series
FreshJet4 series
15°
