MSI924M Using the inverter
17
10.2 Status indications
“Input Level” LED(fig. 5 2, page 4)
The “Input Level” LED shows the present range of the input voltage.
“Load Level” (fig. 5 3, page 4)
The “Load Level” LED shows the power being supplied by the inverter.
10.3 Configuring the inverter
I
You can adjust the device using the dip switch (fig. 5 4, page 4).
Display Input voltage
Red, slow flash < 21.0 V
Green 21.0 – 30.0 V
Red, quick flash > 30.0
Display Output voltage
Off 0 – 80 W
Green 80 – 320 W
Orange 320 – 720 W
Red, slow flash 720 – 800 W
Red, quick flash > 800 W
NOTE
Settings can only be made using the dip switch if the S8 dip switch is
“On”.
The S1 and S2 dip switches have no function.
