Using the inverter MSI924M
18
Setting the mains frequency
!
You can set the mains frequency using the S3 dip switch.
Switching to energy-saving mode
You can set the energy-saving mode using the S4, S5 and S6 dip switches. In this
way, the battery you connect to the inverter is not discharged as quickly.
The inverter operates in energy-saving mode as long as the required power is below
the set level. If the required power exceeds the set level, the inverter works in normal
mode.
The values to be set on your inverter can be found in the following table:
WARNING! Danger of electrocution
Only adjust the S3 DIP switch when the respective frequency for the
output voltage should be used.
Dip switch
Net frequency S3
50 Hz Off
needed for usage with microwave
60 Hz On
Energy-saving
mode
Dip switch
S4 S5 S6
Off Off Off Off
needed for usage with microwave
– On Off Off
70 – 110 W On On Off
180 – 240 W On On On
