Dometic RM3604 User Manual

2
Dometic
®
MANUAL
Refrigerators
SYMPTOM CAUSE
PAGE
REFER
TO
SECTION
Operation 18C 37,38
Level 1J 89
Ventilation 2J 89
Ambient Temperature 5J 90
Air Leaks 3J 89
Thermostat 6C 33
Cooling Unit 6J 90
AC Volts 17C 36
Heating Elements 17C 37
Thermostat 6C 33
LP Gas Pressure 1A 12
Thermostat 6C 33
Filter 8C 33
Orifice 3A 14
Burner 2A 12
Flue Baffle 2A,3A 12,13
Flue Tube 3A 14
Thermostat 9C 33
Wiring B 25-30
Bypass Screw 1C 32
Thermostat 5C 33
LP Gas 1A 12
Safety Valve 2C 32
Thermocouple 3C 32
Thermocouple Adapter, 4C 32
(Top Mount Controls Only)
Flame Failure Meter 7C 33
(Top Mount Controls Only)
Flue Baffle 2A,3A 12,13
Flue Cap (Bottom Mount 3A 14
Controls Only)
Orifice 3A 14
Burner 2A 12
Food Storage 7J 90
Air Leaks 3J 89
Interior Liner Seal to Frame 9J 90
High Humidity 8J 90
DC Volts 15C 36
Heating Element 11C 34
Switch 13C,14C 35
Wiring B 25-30
Relay(RM2610/2810/2604/2804) 10C 34
DC Volts 15C 36
Heating Element 11C 34
Relay (RM2610/2810/2604/2804) 10C 34
Electrode 12C 34
LP Gas 1A 12
Bypass Screw 1C 32
Filter 8C 33
Ignitor 12C 34
8. Insufficient cooling on all modes.
9. Insufficient cooling on electric — cools prop-
erly on other mode(s).
10. Insufficient cooling on gas.
Cools properly on other mode(s).
11. Freezes on electric – cools properly on other
mode(s). (RM2604 & RM2804 ONLY)
12. Freezes on gas – cools properly on other
mode(s). (RM2604 & RM2804 ONLY)
13. Won't stay lit on gas.
14. Rapid formation of frost.
15. No DC operation – cools properly on AC and
gas.
16. Insufficient cooling on DC– cools properly on
AC and gas.
RM2510/RM2610/RM2810/RM2604/RM2804/
RM2552/RM2553
17. On gas mode, sparks while flame is lit.

Dometic RM3604 Specifications

General

Brand	Dometic
Model	RM3604
Category	Refrigerator
Language	English
