B. ELECTRIC OPERATION
Check to be sure the power cord is properly connected
to the power supply. If the refrigerator is equipped for 12
volt DC operation, the tow vehicle engine should be
running to prevent discharging the battery.
Turn knob "A" to the position marked "ELEC" for 120
volt AC operation or "12V" for 12 volt DC operation.
Turn the thermostat knob "B" one-quarter (1/4) of a turn
from the "OFF" position.
To shut off the refrigerator, turn knob "A" to the "OFF"
position.
C. THERMOSTAT
The refrigerator is equipped with a thermostat that can
be adjusted by turning knob "B" to a different setting to
maintain the desired cabinet temperature.
"OFF" Setting of the Thermostat: In gas operation,
the thermostat closes its main valve and the burner runs
continuously at the bypass rate or pilot. In electrical
operation, the contacts in the thermostat are open and
the heating elements are off.
"MAX" Setting of the Thermostat: In gas operation,
the thermostat allows the burner to remain on high flame
continuously. In electric operation, the heating element is
"ON" continuously.
The thermostat can be adjusted between "MAX" and
"OFF" to obtain the desired cabinet temperature. The
closer the knob is to "MAX", the colder the cabinet
temperature. The closer the knob is to "OFF", the
warmer the cabinet temperature.
When the thermostat reaches the set temperature, it will
cut the burner back to bypass or, in electric operation,
shut off the heating element.
20C. OPERATION FOR REFRIGERATORS WITH TOP MOUNT CONTROLS
REFRIGERATORS WITH
AUTOMATIC IGNITION:
RM2552 AND RM2553
LEGEND:
A Energy Selector Knob
B Thermostat Knob
C Flame Failure Safety
Valve Push Button
D Piezo Ignitor
E Flame Indicator
REFRIGERATORS WITH
PIEZO IGNITORS:
RM2452 AND RM2453
