Refrigerators
7
SYMPTOM CAUSE REFER TO PAGE
REFRIGERATOR SECTION
1. No operation - no panel lights Operation 1E 55,56
DC Volts 7E 57,58
Fuse 8E 62
Wiring B 20
Upper Circuit Board 8E 60
Lower Circuit Board 8E 60,61,62
2. No operation - has panel lights Operation 1E 55,56
DC Volts 7E 57,58
Thermistor 8E 58
Fuses 8E 62
Wiring B 20
Lower Circuit Board 8E 60,61,62
3. No AC operation - operates on gas mode Operation 1E 55,56
AC Volts 5E 57
Fuse 8E 62
Heating Element 6E 57
Wiring B 20
Lower Circuit Board 8E 60,61,62
4. No Gas operation - operates on AC mode Operation 1E 55,56
LP Gas 1A 12
Manual Gas Valve 2A 12
Igniter 8E 59
High Voltage Cable 8E 60
Electrode 8E 60
Solenoid 8E 59
Wiring B 20
Lower Circuit Board 8E 60,61,62
5. Insufficient cooling on all modes. Ventilation 2J 89
Leveling 1J 89
Ambient Temperature 5J 90
Air Leaks 3J 89
Thermistor 8E 58
Cooling Unit 6J 90
6. Insufficient cooling on AC - cools properly on AC Volts 5E 57
gas mode. Heating Element 6E 57
Lower Circuit Board 8E 60,61,62
RM2652, RM2852, RM2612 & RM2812 DOMETIC REFRIGERATORS
