3
EN
Slide Topper General Information
• The installation must comply with all applicable local
or national codes, including the latest edition of the
following standards:
U.S.A.
– ANSI/NFPA70, National Electrical Code (NEC)
– ANSI/NFPA 1192, Recreational Vehicles Code
– ANSI Z21.57, Recreational Vehicles Code
Canada
– CSA C22.1, Parts l & ll, Canadian Electrical Code
– CSA Z240 RV Series, Recreational Vehicles
1.4 General Safety Messages
WARNING: FIRE, IMPACT, AND/OR CRUSH
HAZARD. Failure to obey the following
warnings could result in death or serious
injury:
• Use only Dometic replacement parts and
components that are specifically approved for use
with the appliance.
• Avoid improper installation of the Slide Topper.
Installation and maintenance must be done by a
qualified service person only.
• Do not modify this product in any way. Modification
can be extremely hazardous.
• Use care when diagnosing and/or adjusting
components on a powered unit.
• Keep sources of heat and fire (barbecue grills,
portable heaters, etc.) away from the Slide Topper.
• Do not allow children to play with this product or
with fixed controls (if applicable).
• Do not allow anyone (including children) with
reduced physical, sensory or mental capabilities,
or lack of experience and knowledge to use this
product, unless they have been given supervision or
instruction concerning the use of this product by a
person responsible for their safety.
• Never leave an open Slide Topper unattended. Keep
it stowed (closed) when snow, heavy rain, wind, and
severe weather conditions are expected.
CAUTION: PINCH HAZARD.
Maintain a horizontal distance of at least 16 in.
(407 mm) between the fully opened Slide Topper
and any permanent object. Failure to obey this
caution could result in minor or moderate injury.
I
Do not face the slide-out room or Slide Topper
toward permanent objects that my interfere with
the operation.
2 General Information
The images used in this document are for reference
purposes only. Components and component locations
may vary according to specific product models.
Measurements may vary ±0.38 in. (10 mm).
2.1 Finding Tools and Materials
Refer to the following tables for the included, required,
and optional hardware and kits available for the Slide
Topper.
Included Hardware Quantity
Le Hand Topper Arm with 15 in. (38 cm) or 18
in. (46 cm) Extension (Bar)
1
Right Hand Topper Arm with 15 in. (38 cm) or
18 in. (46 cm) Extension (Bar)
1
Cotter R-Pin 2
#10 - 12 x 1 in. Screw 12
#8 - 18 x 3/8 in. Screw 6
#6 - 20 x 7/16 in. Self-Drilling Screw 2
Included Anti-Billow Bracket Kit Quantity
Anit-Billow Stop 1
#10 - 16 x 3/4 in. Screw 2
Anit-Billow Bracket 1
Anit-Billow Spacer 1
#10 - 12 X 3/4 in. Screw 3
3/16 in. X 3/8 in. Oscar Rivet 2
