Photohelic Gauge Installation
#6-32 x 1/4-in
mounting screws
support structure
mounting surface
Photohelic gauge
plastic tubing
high-pressure port
low-pressure port
1/8-in NPT x 90° male elbow
1/8-in NPT adapter
3/8-in flat washer
dirty-air plenum
1/8-in NPT adapter
1/8-in NPT x 90° elbow
static pressure tee
1/8-in NPT x 90° male elbow
1/8-in NPT adapter
3/8-in flat washer
clean-air plenum
1/8-in NPT coupling
mounting bracket
