DoorBird D21DKV - Page 11

ENGLISH
11
1) Night Vision LEDs
2) HDTV Video
3) Microphone
4) Light Sensor
For night-vision mode
5) Security screws
6) Loudspeaker
DEVICE EXAMPLE WITH DISPLAY MODULE
AND KEYPAD MODULE
1
2
3
4
5
6
7
8
9
10
Front
7) RFID Reader
8) Motion Sensor
9) Display Module
10) Keypad Module
The illumination is also acting as
Diagnostic LED(s)
1) Main Electrical Unit
2) Yellow cable for call button
(unused)
3) Red cable for Module Port 1
Connected to the Keypad Module
4) Green cable for Module Port 2
Connected to the Display Module
5) Screw connection terminal
6) LAN/PoE jack
7) Nylon cord
To secure the front panel during
assembly
Inside
5
6
7
2
3
4
1
