Any defects caused by direct sunlight is not covered by warranty.
The network cable between the device and the PoE-Switch/PoE-Injector/Inter-
net Router can have a maximum length of 80 meters/262 feet (IEEE 802.3).
If you have only two wires available at the assembly location, you
may use of the “DoorBird 2-Wire Ethernet PoE Converter A1071”,
sold separately. It allows you to transfer network data (Ethernet) and
power (PoE) with a simple two-wire cable over long distances. For
example; existing buildings with a simple two-wire bell wire can be
equipped with network technology without having to retrofit any
network cables.
STEP : REMOVING THE FRONT PLATE
Remove the front plate carefully using the screw driver provided with the
device from the mounting housing (backbox).
15
ENGLISH
1.) Turn out the
security screws for
1 cm
2.) Pull down the
front panel.
3.) Pull the front panel
towards you.
1cm
