PORT DESCRIPTION
LAN/POE RJ45 jack to connect a standard Network cable Cat.5
or better, coming from the Internet Router/PoE-Switch/
PoE-Injector.
Do not power the device simultaneously via
the power supply from the power supply unit
(mains adaptor) and the power supply via PoE.
REL1, REL1 Bi-stable latching relay #1, max. 1-24 V DC/V AC,
1 Ampere. Security feature: The relay keeps its state even
in the case of loss of power. You can configure the
default state of the relay (open/close) via the DoorBird
App. These ports can be used to connect e.g. an electric
door opener. The device does not supply power to the
connected device. The power supply for the electric door
opener must be installed separately.
When wiring an electric door opener directly
to a door station, there is a risk that the
electric door opener could be tampered by
unauthorized third parties (e. g. by breaking
the door station and short-circuiting the
wiring of the door opener). Therefore, we
generally recommend the use of a remote
safety relay mounted indoors (e. g. DoorBird
I/O Door Controller A1081) for wiring an
electric door opener for a more secure
installation in your home.
REL2, REL2 Bi-stable latching relay #2, max. 1-24 V DC/V AC,
1 Ampere. Security feature: The relay keeps its state even
in the case of loss of power. You can configure the
default state of the relay (open/close) via the DoorBird
App. These ports can be used to connect e.g. an electric
door opener. The device does not supply power to the
connected device. The power supply for the electric door
opener must be installed separately.
When wiring an electric door opener directly
to a door station, there is a risk that the
electric door opener could be tampered by
unauthorized third parties (e. g. by breaking
18
REL2
REL2
REL1
REL1
NOTICE
