Material required for installing the SWING operator and the relevant accessories (if present):
Cable 2x0,5 mm
2
(emitting photocells, pulse generators for opening movement and stop)
Cable 4x0.5 mm
2
(receiver photocells)
Cable 2 x 1.5 mm
2
(power)
Use cables with an adequate degree of insulation.
The electric system must conform to the prescriptions in the chapter entitled “Warnings for the installer”.
The 230 Vac power cable must be laid and connected by a qualified installation technician.
Lay the cables in the appropriate pipes and do not allow loose cables to come into contact with moving parts of the automated system and the
gate.
