INSTALLATION
- To ensure you work in safe conditions, we advise you to install the operator while keeping the door fully closed.
- Use all the specified anchorage points.
- The fastening systems must be suitable for the type of support and sufficiently tough.
- Protect your hands and face adequately while drilling the holes.
- Read this chapter to the full before you begin installing.
1.4 - Attaching Brackets
WELD THE 9 HOLE BRACKET TO THE FIXING PLATE THEN SECURLEY ATTACH THE FIXING BRACKET TO THE PIER OR
POST, OBSERVE MEASUREMENT A AND B BETWEEN THE HINGE PIN AND THE CENTRAL HOLE IN THE BRACKET.
