TECHNICAL SPECIFICATIONS
Swing-5000
Leaf width, m Leaf weight, kg
2.00 1000
2.50 800
3.00 600
4.00 500
5.00 400
Model Swing-3000 Swing -5000
Power supply (V ~ / 50 Hz.) 230
Maximum absorbed power (W) 150 150
Absorbed current 1,2 A
Thrust force (N) 3000 3000
Type of use continuous
Courtesy light (V ~/W) 230 / 25 max.
Standard speed (sm/sec) 1,5
Nut useful travel (mm) 3000 5000
Protection class For indoor use only (IP54)
Operating ambient temperature (°C) -40 / +55
Condenser 10 mkF
Drive Chain
Leaf width, m Leaf weight, kg
2.00 800
2.50 600
3.00 400
Swing-3000
