CONTROL BOARD
Technical specifications
Power supply 230 V~ ( +6% -10%) - 50 Hz
Absorbed power 10 W
Motor max. load 800 W
Accessories max. load 0,5 A
Electric lock max. load 15 VA
Operating ambient
temperature
-20 °C +55 °C
Protection fuses 2 (see fig. 1)
Function logics Automatic / Semi-automatic / "Stepped" Safety device / Semi-automatic B/ Dead-man C
/ "Stepped" semi automatic
Opening/closing time Programmable (from 0 to 120 s)
Pause time 0, 10, 20, 30, 60, 120 s
Closing leaf delay 0, 5, 10, 20 s
Opening leaf delay 2 s (Can be disabled with the dip-switch)
Thrust force Dip-switch adjustable on 8 levels for each motor
Terminal board inputs Open / Open free leaf / Stop / Opening safety devices / Closing safety devices / Power
supply + Earth
Terminal board outputs Flashing lamp - Motors - 24 Vdc accessories power supply - 24 Vdc
