TROUBLESHOOTING
To avoid being electrocuted, only a professional technician is allowed to touch the wires and components on the main panel.
PROBLEM SOLUTION
GATE WILL NOT RESPOND WHEN
GIVEN A COMMAND
1. CHECK POWER SUPPLY TO THE CONTROL PANEL.
2. CHECK CONTROL PANEL FUSES.
3. CHECK HARD WIRE LINK FITTED BETWEEN NC TERMINALS
GATES ARE OPEN BUT WILL NOT
CLOSE AND GREEN LED IS FLASHING
CHECK SAFETY BEAMS ARE WIRED CORRECTLY. (IF MORE THAN ONE SET OF
BEAMS ARE FITTED THEY MUST BE WIRED IN SERIES.)
2. CHECK THAT THERE IS POWER GOING TO THE BEAMS, IF NOT RESTORE POWER.
3. IF SAFETY BEAMS ARE NOT FITTED ENSURE THAT A HARD WIRE LINK IS FITTED
BETWEEN NC TERMINALS
4. REMOVE SAFETY BEAM WIRES FROM CONTROL PANEL AND CHECK IF YOU HAVE
A NORMALLY CLOSED CIRCUIT COMING FROM THE BEAMS.
WHEN COMMISSIONING GATE
AUTOMATICALLY OPENS BUT DOES
NOT AUTOMATICALLY CLOSE
MOTOR WIRES ARE WRONG WAY ROUND. CHECK AND PROVE MOTOR DIRECTION
BY MOMENTORIALLY PULSING MOTOR TERMINALS
THEGATE SHOULD OPEN UP.
GATES WILL NOT RESPOND TO REMOTE
CONTROL COMMAND
1. AF FREQUENCY CARD NOT FITTED TO CONTROL PANEL.
2. REMOTE CONTROL HAS NOT BEEN PROGRAMMED INTO THE CONTROL PANEL.
3. REMOTE CONTROL HAS THE WRONG CODE SETTING.
4. “OPERATOR PRESENT” HAS NOT BEEN SELECTED TO DEACTIVATE RADIO REMOTE
CONTROLS (DIPSWITCH 1).
5. WRONG FREQUENCY CARD FITTED FOR THE REMOTE CONTROL.
