1.5 - Attaching the Rear Bracket
THE REAR BRACKET IS EQUIPPED WITH ADDITIONAL HOLES TO MAKE INSTALLATION OF THE GATE MOTOR EASIER, OR
TO CHANGE THE OPENING ANGLE OF THE GATE. THE REAR BRACKET CAN BE LENGHENED OR SHORTENED TO SUIT THE
INDIVIDUAL INSTALLATION SITE AND THE POSITION OF THE GATES (WITH RESPECT TO THE PILLARS).
N.B IF MEASUREMENT B IS INCREASED, THE ANGLE OF APETURE IS REDUCED. THIS THEREFORE REDUCES THE
PERIPHERAL SPEED AND INCREASES THE THRUST EXERTED BY THE MOTOR ON THE GATE. IF MEASUREMENT A IS INCREASED,
THE ANGLE OF APERTURE IS INCREASED. THIS THEREFORE INCREASES THE PERIPHERAL SPEED AND REDUCES THE THRUST
EXERTED BY THE MOTOR ON THE GATE.
WHEN THE REAR BRACKET IS SECURELY ATTACHED TO THE PIER OR POST, INSERT THE BUSH INTO THE DESIRED HOLE
AND ATTACH THE REAR JOINT ARM, LUBRICATING WITH A NEUTRAL GREASE.
