6006-065-B-3-20
15
See the 115 VAC control box Wiring/Owner’s
manual OR Solar control box Wiring/Owner’s
manual to wire entrapment protection devices.
Gate Frame (Closed)
Monitored
Reversing
Edge
Potential
Entrapment
Area
Mointored Reversing Edge Note:
Input is active in BOTH directions of gate travel.
Reversing Edge
A monitored reversing edge (Type B2) or a monitored photo sensor (Type B1, see previous page) MUST be installed in EACH
entrapment area or operator WILL NOT function.
Typical Monitored Reversing Edge mounted on end of gate.
Entrapment protection
is RECOMMENDED for
this area.
If the distance between an entrapment or obstruction
exists less than 16” from the open gate, then
entrapment protection is REQUIRED for this area.
OPTIONAL wireless transmitter can be used.
Receiver MUST monitor for the presence of the transmitter.
Note: If bottom edge of gate is less than 4” (10.1 cm)
or greater that 16” (40.6 cm) above the ground, then
NO reversing edge is required on bottom of gate.
Monitored Edge
Transmitter
2-Wire End-of-Line Edge
2-Wire
End-of-Line
Edge
Entrapment Protection Locations Continued
Reversing Edges are wired in series
OPTIONAL wireless transmitter can be used.
Receiver MUST monitor for the presence of the transmitter.
Monitored Edge
Transmitter
4-Wire In-Line Edge
2-Wire End-of-Line Edge4-Wire In-Line Edge
Typical Wireless Reversing
Edges mounted on bottom and
end of gate when needed.
If the bottom of gate is greater than 4” (10.1 cm)
but less than 16” (40.6 cm) above the ground
at any point in its arc of travel, entrapment
protection is REQUIRED for this area.
Greater than 4” (10.1 cm) but
less than 16” (40.6 cm)
Gate in Open Position
(Open to the outside
shown here)
To Next Page
