3) P086TI
- 9 -
EA9O1005
12
8 9 10 12 13
16
11
34 5 67 1415
17
18 19 20 21
22
22
23
1. Cooling fan 8. Vibration damper 17. Intake manifold
2. Thermostat 9. Oil cooler 18. Injection pump
3. Oil filter cap 10. Oil fan 19. Oil filter
4. Air pipe 11. OIl drain valve 20. Oil level gauge
(Turbocharger to 12. Starter 21. Air pipe
Intake manifold) 13. Flywheel housing
(Intercooler to Intake manifold)
5. Turbocharger 14. Cylinder head 22. Mounting bracket
6. Exhaust elbow 15. Cooling water pipe 23. Water pump
7. Breather 16. Flywheel
