Doosan D1146T User Manual

•
D1146 / D1146T / PU086 / PU086T (24V X 4.5kW)
Always protect starter motor against moisture.
WARNING :
Always disconnect the battery earth cable before starting work on the electrical system.
Connect up the earth cable last, as there is otherwise a risk of short-circuits.
- 27 -
50
EA9O2010
30
MAGNET
SWITCH
STARTER
MOTOR
STARTER S/W
24V X 4.5kW
EA902009
Wiring Diagram
