P086TI (24V X 6.0kW)
- 26 -
TERMINAL "B"
M10 x P1.5
TERMINAL S/W
M5 x P0.8
EA8O3008
24V x 6.0kW
2.5A(20
o
C 24V)
M
EA8O3009
Motor
S/W
KS
S/W
S/W
S
B
B
M
Wiring Diagram
24V x 6.0kW
