Doosan D20S-7 - Specifications

General Section
-31-
Specifications
CHARACTERISTICS
1 MANUFACTURER
DOOSAN DOOSAN
2 MODEL
D20S-7
(D24NAP,TIER4)
D25S-7
(D24NAP,TIER4)
3 CAPACITY at rated load center kg
2000 2500
4 LOAD CENTER distance mm 500 500
5 POWER TYPE electric, diesel, gas, LPG-gas diesel diesel
6 OPERATOR TYPE stand-on, ride-seated rider-seated
rider-seated
7 TIRES C=cushion, P=pneumatic p
p
8 WHEELS(x=driven) number of front/rear 2/2
2/2
DIMENSIONS
9
LIFT WITH STD
TWO-STAGE MAST
maximum fork height with rated load mm
3230 3230
10 free lift mm 152 152
11 FORK CARRIAGE ISO class II
II
12
FORKS
thickness x width x length mm
45x100x1000 45x100x1000
13 fork spacing (maximum x minimum) mm
275x1035 275x1035
14 TILT OF MAST forward/backward deg 6/10 6/10
15
OVERALL
DIMENSIONS
length to fork face mm 2530 2595
16 width mm
1170 1170
17 mast lowered height mm
2175 2175
18 mast extended height mm
4490 4490
19 overhead guard height mm
2183 2183
20 seat height mm
1026 1026
21 OUTSIDE TURNING RADIUS mm 2220
2265
22 LOAD MOMENT CONSTANT mm
485 485
23
90。 STACKING AISLE
mm
2705 2750
23
a
90。 INTERSECTING AISLE mm
1970 2000
PERFORMANCE
24
SPEED
travel, loaded/unloaded km/hr 21/22 21/22
25 lift, loaded/unloaded mm/s
530/580 520/580
26 lowering, loaded/unloaded mm/s 500/450 500/450
27 DRAWBAR PULL at 1.6km/hr, loaded/unloaded kg 1790/1760 1790/1780
28 GRADEABILITY at 1.6km/hr, loaded/unloaded %
33 28
29 ACCELERATION
time reached at max speed,
loaded/unloaded
sec
WEIGHT
30 TOTAL WEIGHT at unloaded kg 3690 4065
31
AXLE LOAD
at loaded, front/rear kg 4965/725 5695/870
32 at unloaded, front/rear kg 1750/1940 1680/2385
CHASSIS
33
TIRES
number of front/rear 2/2 2/2
34 front size 7.00x15-12 7.00x15-12
35 rear size 6.50x10-10 6.50x10-10
36 WHEEL BASE mm 1625 1625
37 TREAD front/rear mm 975/1000 975/1000
38
GROUND
CLEARANCE
at loaded, the lowest point mm 115 115
39 at loaded, center of wheelbase mm 143 143
40 SEVICE BRAKE foot/hyd foot/hyd
41 PARKING BRAKE hand/mech hand/mech
DRIVE
42 BATTERY voltage/capacity V/AH 12/85 12/85
43
ENGINE
manufacturer/model
DI/D24NAP
TIER-4
DI/D24NAP
TIER-4
44 rated output / rpm kw(hp) 45.6(62)/2200 45.6(62)/2200
45 max. torque / rpm N-m(lb•ft) 262(193)/1600 262(193)/1600
46 cycle/cylinders/displacement cc 4/4/2392 4/4/2392
47
TRANSMISSION
type powershift powershift
48 number of speeds forward/reverse 1/1 1/1
49
OPERATING
PRESSURE
system/attachment bar 181/156 195/156
50 NOISE LEVEL
equivelent continuous sound
pressure level (Leq) at operator's ear
(DI : BITA/CE prEN 12053)
dB(A)
