Operation Section
-56-
13. Mast interlock – Alarm warning lights
when operator leaves the seat without
applying parking brake and then,
operation of mast is automatically
interrupted.
14. Directional Turning Indicator Light
15. Brake oil level – Brake oil level Lamp
indicates when the brake oil level is low.
16. ECT Malfunction Warning Lamp (if
installed) – electronic transmission
control system has a built-in diagnosis
system. If a failure occurs, the electronic
transmission control system reports the operator of
the failure code by the number of flashes with the
malfunction warning lamp.
17. Engine oil pressure warning lamp –
The warning lamp will light up if the
engine oil is short or the pressure is low.
18. Fuel warning lamp – The warning
lamp will light up to warn the operator to
refuel.
19. Horn Switch - Push on the horn button
to sound the horn.
20. Front and Rear Floodlights Switch – The
front floodright is ON when push down switch to
the first step.
The front and rear floodlights are ON when push down
switch to the second step.
21. Speedometer – Shows vehicle
speed
