Product Specifications
1. General specifications
2. Mechanical specifications
Item GN11 (DWA-2000) GN12 (GNSA-2002)
Operating voltage (kg/lit) DC 24V DC 24V
Max. fuel quantity (°C) Adjust Adjust
Production capacity (40°C) (cst) 200 ~ 1,000 KW 150 ~ 250 KW
Allowable humidity (wt%) 100% 100%
Operating current (°C) 1.5 A 2.0 A
Max. operating current (°C) 4.5 A 3.1 A
Rack operating power (°C) 58.7 N 27.5 N
Rack operating range (ASTM) 20 mm 21 mm
Engine injection pump specs. Right rack type Right rack type
Item GN11 (DWA-2000) GN12 (GNSA-2002)
Product dimensions 107.1 x 180.4 x 196.5 112 x 205 x 101
Product weight 4.9 kg 2.6 kg
Installed engine (Bosch type) P 3000, P 7000 AD Series
Material for exterior AL (ALDC-12) AL (ALDC-12)
Material for core Pure iron Pure iron
Coil size and no. of turns Ø0.85 / 715 Ø0.6 / 790
