3. State of adjustment at time of factory release
CW: Clockwise, CCW: Counterclockwise
CW: Clockwise, CCW: Counterclockwise
300611-00683
Overspeed 1,725 rpm (based on 160 gear teeth)
Run lamp Maximum CW
Gain Mid-range (facing 12 o’clock)
Stability Mid-range (facing 12 o’clock)
Starting Fuel Full CW (Maximum Fuel)
Speed Ramping Facing 9 o’clock
Droop Full CCW (Minimum)
E.M. Speed Adjustment (160 gear teeth)
Speed Adjustment 4,000 Hz (1,500 rpm)
Idle Adjustment 2,133 Hz (800 rpm)
300611-00684
Overspeed 1,725 rpm (based on 160 gear teeth)
Run lamp Maximum CW
Gain Mid-range (facing 12 o’clock)
Stability Mid-range (facing 12 o’clock)
Starting Fuel Full CW (Maximum Fuel)
Speed Ramping Facing 9 o’clock
Droop Full Full CCW (Minimum)
E.M. Speed Adjustment (160 gear teeth)
Speed Adjustment 4,800 Hz (1,800 rpm)
Idle Adjustment 2,133 Hz (800 rpm)
