1. Cooling fan 10. Cooling water pipe 18. Air pipe
2. Alternator (from radiator) (Turbocharger to
3. Thermostat 11. Oil cooler Intake manifold)
4. Oil filter cap 12. OIl drain valve 19. Intake manifold
5. Cylinder head cover 13. Flywheel housing 20. Fuel filter
6. Exhaust manifold 14. Flywheel 21. Starter
7. Breather 15. Exhaust elbow 22. Injection pump
8. Vibration damper 16. Turbocharger 23. Water pump
9. Oil filter 17. Cylinder head cover 24. Mounting bracket
