9.1.19. Intake manifold
•
Remove the Intake manifold assem-
bling bolts and disassemble it from the
cylinder head.
•
Disassemble the intake manifold gas-
ket and scrap it.
9.1.20. Cooling water pipe
•
Remove the cooling water pipe
assembling bolts and disassemble the
pipe for the cylinder head.
•
Remove the gasket of cooling water
pipe with a scraper thoroughly.
Caution :
Be careful for the gasket pieces not to
get in the passage of cooling water.
9.1.21. Rocker arm
•
Remove the rocker arm bracket
assembling bolts in the reverse order
(zigzag method) of assembling and
disassemble the rocker arm.
•
Disassemble the push rod.
9.1.22. Cylinder head
•
Remove the cylinder head bolts in the
reverse order of tightening but remove
it step by step.
First step : Loosen 1 ~ 2 threads
Second step :
Remove by loosening
fully.
However, remove the total bolts simul-
taneously by the step of 1 and 2.
- 71 -
