MUXD 19" (B6L 19")
6. Technical data
26
MUXD 19" technical data
Power supply
16 VDC to 36 VDC (SELV)
with internal power supply unit
230/115 V/50...60 Hz
Power consumption
with internal power supply unit
max. 45 W
up to 200 W, with external power supply unit
(depending on power supply unit used)
Interfaces
Host: RS485
Service: RS232
SubBus: 8x / 16x RS485
Max. 31 devices
Anti-tamper contact
available
Connection cable
See General Installation Guidelines.
Ambient conditions
Operating temperature range: -20 ºC to +40 ºC
Storage temperature range: -20 ºC to +70 ºC
Humidity range: 0 to 80%, non-condensing
General design
EN 60 950-1, protection class III (for 230/115 V operation,
protection class I)
Protection rating
IP30
Resistance to interference
EN 61000-6-2
Immunity for industrial environments (complies with the
increased requirements according to VdS 2358, directives
for access control systems)
Interference emissions
EN 61000-6-3 Emission standard for residential, commer-
cial and light-industrial environments
Abmessung
(W x H x D) 407 x 44 x 305 mm
Housing colours
Front bezel, aluminium
Housing, RAL7016 (anthracite grey)
Weight
approx. 5 kg
Display
Status display via LEDs
Installation height and footprint
A minimum of 100 mm depth clearance must be allowed
for the cable outlets and the 230 V connecting cable
Versions
Installation in 19" cabinet
We reserve the right to make technical modifications and improvements that assist the further development of our equipment.
