MUXD 19" (B6L 19")
1. General Information
66
1.4 Functional principle
The MUXD terminal multiplexer allows simple installation of
DP1 or TP4 components in a star configuration. The advan-
tage of the MUXD module, as opposed to bus wiring, is that
it allows spurs to be used. Either DP1 or TP4 components
with up to 2 x 8 RS485 buses can be connected to a TP4
host system.
A maximum of 31 two-wire components can be connected
to the MUXD module.
The MUXD module is transparent for protocols to and from
the host. The delay time is a maximum of three byte peri-
ods. Simultaneous operation of DP1 and TP4 with an MUXD
is not possible.
A cascading of the MUXD is not permitted.
Housing:
Because structured wiring techniques are required, the
device is installed in a 19'', 1HE housing similar to B6L.
A maximum of two MUXD modules can be accommodated
in the 19" housing, so up to 2 x 8 two-wire buses are avail-
able.
Host system:
Either the TP4 host system is an external device, e.g. B6L,
or the TP4 module is combined directly with the MUXD in
the same housing. This results in a compact, LAN-compat-
ible host system to which up to 31 DP1 or TP4 two-wire
components can be connected in a star configuration.
1.4 Further Sources of Information
Further documents are available on request.
General Installation Guidelines
Specifications for planning attendance recording and
access control systems with our wired components.
Planner Manual
Examples of cross-system solutions
1.5 Disposal
The device was manufactured using recyclable materials and
components.
When disposing of the device and the packaging, please
ensure environmentally friendly recycling.
Information for EU Countries
European Directive 2002/96 EC applies to this device.
This means that this product must not be disposed of with
normal household waste. We, the manufacturer, will take
back our electric and electronic products and dispose of
them for you free of charge. Correct disposal of your old
equipment protects people and the environment from
possible harmful consequences.
Rechargeable/disposable batteries
This device contains an integrated lithium battery.
According to European directive 2006/66/EC, disposable and
rechargeable batteries must not be disposed of with normal
household waste.
Please check your local regulations for separate disposal of
batteries. Correct disposal of batteries protects people and
the environment from possible harmful consequences.
