Dorma MUXD 19 User Manual

MUXD 19" (B6L 19")
1. General Information
7
1.5 Components supplied:
A B6L 19'' / MUXD 19"
B Assembly instructions
C 2 x angle profiles
D 4 x countersink screws
E 4 x washers
F 4 x cage nuts
G 4 x round head screws
H 1 x IEC cable (2,5m)
(for 230/115V only)
I 1 x cable (4m)
(for 24V only)
1.6 Variants
A
B
C
x
x
x x
DORMA
Montageanleitung
MD 
D
x


B6L 19''
MUXD 19''
Internal Voltage
Supply Voltage
SubBus1 Activity
SubBus Power
SubBus2 Activity
Booking Activity
Tamper Status
System Run
Reset
ext. POWER
LAN-Activity
RS232 Service
LAN 10/100 BaseTx
LAN Link / Spee
d
ext. POWER
1-2 x MUXD modules, 1 x TP4 basic card
1 x MUXD module

Dorma MUXD 19 Specifications

General

Brand	Dorma
Model	MUXD 19
Category	IP Access Controllers
Language	English
