Dormakaba TS 73 EMF - Page 4

4
dormakaba TS 73 EMF
24 V DC
109,5
193,5 50 5022
45222
67,5
31
95,5
110
1545
38
min. 255/max. 365 mm
ø 20 (24 V DC)
45222
109,5
193,5 505022
67,5
31
37,5
415,5
45
15
38
min. 255/max. 365 mm
X
75°75°75°
RM-NRM-N
TS 73 EMF
Transom fixing, push side
Door leaf fixing, pull side
Example: LH/ISO 6 door; mirror image for RH/ISO 5 door.
Example: RH/ISO 5 door; mirror image for LH/ISO 6 door.
Door opening up to 180° requires min. 26 mm pivot
offset at the hinges or a corresponding wall recess
for the door closer.
Example application: Hold open system TS 73 EMF + RMZ + 2x RM-N
Door opening up to 180° with standard arm only possible where X ≤ 70 mm
Recommended cabling:
I - Y (St) Y 2 x 2 x 0,6
