5
16
42
65
ø
5,5
32,5
160
14
ø
20
320
16
11
16
43
60
58
6
12
26
45
70 – 135
45
16
145
min. 305 mm/max. 420 mm
295
M 10
250
45
16
145
min. 325 mm/max. 425 mm
295
320
M 10
82
82
18
51
AP
UP
Accessories
Mounting backplate
For pull and push side fixing
For mounting the TS 73 EMF
to fire and smoke check
doors and also doors in
which no direct fixing is
possible.
Hinge plate
For pull-side installation of
the arm on particularly
narrow door frames.
Extended adjustable arm
For push side fixing.
For adapting the TS 73 EMF
to door sets with frame
reveal depths between 70
and 135 mm.
Extended arm assembly
For push side fixing.
For increasing the door
opening to 180° in door sets
with a frame reveal depth of
max. 70 mm and where
X < 70 mm.
HT manual switch
A manual release switch
may be installed to release
doors if required.
close
door
HT-
UP
HT-
AP
