Doyon 1T - 1 T Oven Front View Parts List

To Next Page

To Previous Page

Front view

Item Part Number Description Quantity

1 MPA168 LOCKING CASTER (FRONT OF THE OVEN) 2

& MPA167 NON LOCKING CASTER (BACK OF THE OVEN) 2

2 PA0341C LEGS WITHOUT CASTERS (25") 4

OR PA0342C LEGS WITHOUT CASTERS (16") 4

OR PA0343C LEGS WITHOUT CASTERS (13") 4

OR PA0344C LEGS WITHOUT CASTERS (1") 4

3 PA009CN BLACK KNOB FOR STEAM DAMPER (CN CHAMBER) 1

OR PA009CA BLACK KNOB FOR STEAM DAMPER (CA CHAMBER) 1

OR PA009SA BLACK KNOB FOR STEAM DAMPER (SA CHAMBER) 1

OR PA009SS BLACK KNOB FOR STEAM DAMPER (SS CHAMBER) 1

4 MPP089 DOOR HANDLE 1

& FMB601 DIA. 5/16” WASHER 1

& AZRB200 DIA. 5/16” LOCK WASHER 1

& FMB552 M8 NUT 1

& MPP211 ALLUMINIUM CAP NUT 1

5 PA023-1TCN DOOR FRAME INCLUDES BOTH GLASSES (NO HANDLES) 1TCN 1

OR PA023-1TCA DOOR FRAME INCLUDES BOTH GLASSES (NO HANDLES) 1TCA 1

OR PA023-1TSA DOOR FRAME INCLUDES BOTH GLASSES (NO HANDLES) 1TSA 1

OR PA023-1TSS DOOR FRAME INCLUDES BOTH GLASSES (NO HANDLES) 1TSS 1

6 MPV001 EXTERIOR TINTED DOOR GLASS (18 7/16"x4 3/4"x1/4") 1TCN 1

OR MVP003 EXTERIOR TINTED DOOR GLASS (18 7/16"x6 3/4"x1/4") 1TCA 1

OR MVP005 EXTERIOR TINTED DOOR GLASS (18 7/16"x8 3/4"x1/4") 1TSA 1

OR MVP007 EXTERIOR TINTED DOOR GLASS (18 7/16"x10 3/4"x1/4") 1TSS 1

7 MEC024 MAIN SWITCH KNOB 1

& MEC031 MAIN SWITCH LIGHT’S SOCKET 1

& MEC034 MAIN SWITCH CONTACT (NO) 1

& MER061

8 MEC008 CONTROL PANEL 1

& MEC066 OVEN THERMOCOUPLE TYPE K 1

& MEC067 STEAM THERMOCOUPLE TYPE K 1

9 MPR037 STONE DECK FOR 1T (PINK) 1

OR PA021R-1T

10 MVP002 INTERIOR NON TINTED DOOR GLASS (15 1/4"x4 3/4"x1/4") 1TCN 1

OR MVP004 INTERIOR NON TINTED DOOR GLASS (15 1/4"x6 3/4"x1/4") 1TCA 1

OR MVP006 INTERIOR NON TINTED DOOR GLASS (15 1/4"x8 3/4"x1/4") 1TSA 1

OR MVP008 INTERIOR NON TINTED DOOR GLASS (15 1/4"x10 3/4"x1/4") 1TSS 1

11 MPR021 1

1T ARTISAN DECK OVEN (FRONT VIEW)
