Doyon 1T - 1 T Oven Side View Parts List

E4
Side view
Item Part Number Description Quantity
1 MER001 ELEMENT BLOCK 208V – 240V (1T) 12
OR MER001A ELEMENT BLOCK 480V (1T) 12
2 MER011 LIGHT BULB TYPE MR16 1
& MER019 SOCKET FOR 20W LIGHT BULB 1
3 MER068 TRANSFORMATOR 240V > 12V, 24V 1
& TRANSFORMATOR 240 > 24 IF WATER SOLENOID VALVE IS 24 VAC 1
4 TERMINAL BLOCK FOR BUZZER 2
5 MEC042 1
& MEC042B 1
6 TERMINAL BLOCK FOR CONTROL 6
7 MEC062 CONTACTO FOR OVEN ELEMENTS 3
8 MEC062 CONTACTOR FOR STEAM ELEMENT 1
9 MEP054 TRIPLE BREAKER 40A 1
10 DOUBLE BREAKER 10A 1
11 MEP005 DOUBLE BREAKER 6A 1
12 MEP003 SINGLE BREAKER 10A 1
13 MEL159 TERMINAL BLOCK 1
& MEL157 GROUND TERMINAL BLOCK 1
1T ARTISAN DECK OVEN (SIDE VIEW)
