E14
Front view
Item Part Number Description Quantity
1 MPA168 LOCKING CASTER (FRONT OF THE OVEN) 2
& MPA167 NON LOCKING CASTER (BACKOF THE OVEN) 2
2 PA0341C LEGS WITHOUT CASTERS (25") 4
OR PA0342C LEGS WITHOUT CASTERS (16") 4
OR PA0343C LEGS WITHOUT CASTERS (13") 4
OR PA0344C LEGS WITHOUT CASTERS (1") 4
3 PA009CN BLACK KNOB FOR STEAM DAMPER (CN CHAMBER) 1
OR PA009CA BLACK KNOB FOR STEAM DAMPER (CA CHAMBER) 1
OR PA009SA BLACK KNOB FOR STEAM DAMPER (SA CHAMBER) 1
OR PA009SS BLACK KNOB FOR STEAM DAMPER (SS CHAMBER) 1
4 MPP089 DOOR HANDLE 1
5 PA0233TCN DOOR FRAME INCLUDES BOTH GLASSES (NO HANDLES) 3TCN 1
OR PA0233TCA DOOR FRAME INCLUDES BOTH GLASSES (NO HANDLES) 3TCA 1
OR PA0233TSA DOOR FRAME INCLUDES BOTH GLASSES (NO HANDLES) 3TSA 1
OR PA0233TSS DOOR FRAME INCLUDES BOTH GLASSES (NO HANDLES) 3TSS 1
6 MPV017 EXTERIOR TINTED DOOR GLASS (55 5/8”x4 ¾”x1/4”) 3TCN 1
OR MVP019 EXTERIOR TINTED DOOR GLASS (55 5/8”x6 ¾”x1/4”) 3TCA 1
OR MVP021 EXTERIOR TINTED DOOR GLASS (55 5/8”x8 ¾”x1/4”) 3TSA 1
OR MVP023 EXTERIOR TINTED DOOR GLASS (55 5/8”x10 ¾”x1/4”) 3TSS 1
7 MEC024 MAIN SWITCH KNOB 1
& MEC031 MAIN SWITCH LIGHT 1
& MEC034 MAIN SWITCH CONTACT (NO) 1
8 MEC008 CONTROL PANEL 1
& MEC066 OVEN THERMOCOUPLE TYPE K 1
& MEC067 STEAM THERMOCOUPLE TYPE K 1
9 MPR044 STONE DECK FOR 3T 1
10 MVP018 INTERIOR NON TINTED DOOR GLASS (52 3/8”x4 ¾”x1/4”) 3TCN 1
OR MVP020 INTERIOR NON TINTED DOOR GLASS (52 3/8”x6 ¾”x1/4”) 3TCA 1
OR MVP022 INTERIOR NON TINTED DOOR GLASS (52 3/8”x8 ¾”x1/4”) 3TSA 1
OR MVP024 INTERIOR NON TINTED DOOR GLASS (52 3/8”x10 ¾”x1/4”) 3TSS 1
11 MPR021 1
3T ARTISAN DECK OVEN (FRONT VIEW)
