A-24
INSTRUCTION TO REVERSE DIRECTION OF THE CONVEYOR
FC2
To reverse the direction of the conveyor on FC2 oven, follow the instructions at page A-20.
FC18
When you reverse the conveyor direction, you have to install the extension shelf on the other side of the
conveyor (see picture A). Unscrew the pizza stopper [1] and screw to the other side of the extension
[2].
To reverse the direction of the conveyor, open the back panel of the oven. (picture B) Disconnect the
red and black wire of the conveyor motor on the gray terminal block and invert the two wire. (picture
C) The conveyor should run in the other direction.
To reverse on some models with the optional directional switch, change the position of the switch
(picture D and E) located beside the conveyor motor from position I to II.
WARNING: Shut off the main power switch of the oven before reversing the conveyor.
C
B
A
1
2
E
D
