A-12
INSTRUCTIONS TO REMOVE THE CONVEYOR AND CLEAN
THE OVEN FC18G
1. Turn the power off ( A ).
♦ Remove the extended shelf ( B ).
♦ Remove the right tray ( C ).
3. Right tray ( C ).
♦ To remove the tray :
♦ Push ( 1 ) to the left (5mm), then lift
(10mm), then pull to the right ( 3cm )
♦ Pull the tray in the same direction as
indicated in ( 2 ) above.
2. Extended shelf ( B ). 4. Left tray ( D ).
A C B
12
D
To Next Page
