59160001-MCSC Edition 06 08.05.2013 / Bak page 10/34
4. Operating the light MACH LED 2MC/SC
4.1. Turning the light ON and OFF
The push button 1 on the control panel turns the light
Mach LED 2
MC/SC ON and OFF.
4.2. Adjusting the light field with the
sterilisable handle
The light field can be adjusted by turning the sterilis-
able handle 2.
The current size of the light field is shown by the digi-
tal display 3.
2
3
