Mach LED 2MC/SC
Dr. Mach
Lamps and Engineering
59160001-MCSC Edition 06 08.05.2013 / Bak page 9/34
3. Light functions operated at the sterilisable handle
Depth light
The depth light can be activated by a tight-turn
of the ring at the sterilisable handle. A left-turn
of the ring switches the depth light OFF.
The depth light function on the ring is pre-
set by Dr. Mach at delivery. The customer can
transfer all other available functions of the
LED-light to the ring on request. The transfer
procedure is described in the following chap-
ters.
Merging of light fields
The four light fields of the outer LED-units are
merged to one light field by turning the handle
sleeve.
1 1
2 2
