13. Electromagnetic compatibility
The Dr. Mach OT- and examination lights are subject to special preventive measures regarding the elec-
tromagnetic compatibility and must be installed according to the EMC-instructions mentioned in the ac-
companying documents.
The function of the OT- and examination lights can be affected by portable and mobile HF-communication
devices.
Table 1 – Guidance and manufacturer´s declaration – electromagnetic emission – for all EQUIPMENT AND SYSTEMS
(see 5.2.2.1 c)
1 Guidance and manufacturer´s declaration – electromagnetic emission
2
The MACH LED 2MC/SC is intended for use in the electromagnetic environment specified below. The
customer or the user of the MACH LED 2MC/SC should assure that it is used in such an environment.
3 Emissions test Compliance Electromagnetic environment - guidance
7
Harmonic emissions
IEC 61000-3-2
Class C
The MACH LED 2MC/SC is suitable for use in all
establishments, including domestic establishments and those directly con-
nected to the public low-voltage power supply network that supplies buildings
used for domestic purposes.
8
Voltage fluctuations /
flicker emissions
IEC 61000-3-3
Complies
12
RF emissions
CISPR 15
Complies
The MACH LED 2MC/SC is not suitable for interconnection
with other equipment.
Table 2 – Guidance and manufacturer's declaration – electromagnetic immunity – for all EQUIPMENT and SYSTEMS
(see 5.2.2.1 f)
Guidance and manufacturer´s declaration – electromagnetic immunity
The MACH LED 2MC/SC is intended for use in the electromagnetic environment specified below. The customer
or the user of the MACH LED 2MC/SC should assure that it is used in such an environment.
Immunity test
IEC 60601
test level
Compliance level
Electromagnetic environment -
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood, concrete or
ceramic tile. If floors are covered with
synthetic material, the relative humidity
should be at least 30 %.
Electrical fast
transient / burst
IEC 61000-4-4
± 2 kV for power
supply lines
± 1 kV for input/output lines
± 2 kV for power
supply lines
not applicable
Mains power quality should be that of a
typical commercial or hospital
environment.
Surge
IEC 61000-4-5
± 1 kV differential
mode
± 2 kV common mode
± 1 kV differential
mode
± 2 kV common mode
Mains power quality should be that of a
typical commercial or hospital
environment.
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
< 5 % U
T
(>95 % dip in U
T
)
for 0,5 cycle
40 % U
T
(60 % dip in U
T
)
for 5 cycles
70 % U
T
(30 % dip in U
T
)
for 25 cycles
< 5 % U
T
(>95 % dip in U
T
)
for 5 sec
< 5 % U
T
(>95 % dip in U
T
)
for 0,5 cycle
40 % U
T
(60 % dip in U
T
)
for 5 cycles
70 % U
T
(30 % dip in U
T
)
for 25 cycles
< 5 % U
T
(>95 % dip in U
T
)
for 5 sec
Mains power quality should be that of a
typical commercial or hospital environment. If
the user of the
MACH LED 2MC/SC requires
continued operation during power
mains interruptions, it is recommended
that the MACH LED 2MC/SC be powered
from an uninterruptible power supply or a
battery.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m 30 A/m
Power frequency magnetic fields should be at
levels characteristic of a typical location in a
typical commercial or hospital environment.
NOTE U
T
is the a. c. mains voltage prior to application of the test level.
